Shank Type Blade/Groover Adapter for CNC
Blade/Grooving Adapter for CNC Machining on HSK Heat Shrink Holder

SHANK ADAPTER FOR SAW BLADES UP TO 8″

$279.85$363.25

Series 6374 Shank Adapter arbor facilitates mounting of grooving blades and smaller diameter saw blades on CNC Machining Centers.  Standard saw blades are modified to add countersunk pinholes to fit this adapter. The maximum blade thickness permissible is 10mm. Blade thickness of less than 3.5mm requires use of an additional clamping ring for stability (included). Maximum blade diameter is 200mm (8”). Made in Germany

It is highly recommended that this adapter be purchased with a heat shrink tool holder where possible for maximum accuracy.

SKU: N/A Category:

Available Options:

Description

Shank Adapter arbor facilitates mounting of grooving blades and smaller diameter saw blades on CNC Machining Centers.  The maximum blade thickness allowable is 10mm. Blade thickness of less than 3.5mm requires use of an additional clamping ring for stability (included). Maximum blade diameter is 200mm (8”) .   Made in Germany
It is recommended that this adapter be purchased with a heat shrink tool holder where possible for maximum accuracy.

Additional information

D

22mm, 30mm

L1

90mm, 74mm

L2

4mm

TK

36mm, 48mm

Shank

3/4"x65mm, 25x65mm, 16x60mm
